Paper roll slitting rewinding machine

Share to:

Send Inquiry

Gift wrap paper slitting rewinding machine

PPD-RW900

Gift wrap paper slitting rewinding machine PPD-RW900 is designed for slit the jumbo roll of various gift wrapping paper into small roll for individual use.
Production complete With Auto Loading of Unwind Jumbo Rolls,Auto Loading of Re-wind paper feeding into the Rewinding station,auto unloading when product is ready from rewinding station.

As per CE certificate requirement,we build Safety abrrier system for auto stop cover of gear housing of unwind station.
Our machine is improted technology from Japan,it is at 40mm thickness wall frame to stablize machine,all premium world top class of PLC,LCD,inveter etc.
Auto control of magnetic powder break system at 100Nm for precision length contorl cowork with premium meter counting system,Auto tension controller It is compact,Steady for performing,Easy for operation,High production speed.

As value added,This same model is ideal for slit bond paper,craft paper roll,cash paper roll etc too.

BRIEF TECHNICAL DATA:

Maximum Width : 900 mm
Maximum Mother Reel Dia : 1200 mm
Slitting Width (Standard) : Adjustable Width Maximum 900mm
Maximum Rewind Diameter : 180mm dia.
Rewind Core Diameter : 12.7,25,38mm - Option
Cutting Speed : 150m per minute
Machine Overall Dimension :1600x1500x1600mm
Nett Weight of Machinery : 2 M/Ton
Power Voltage : 220/380/415V 50&60hz
Total Power : 2.2kw (kilowatt)



Gift wrap paper slitter rewinder machine, gift wrapping paper roll cutting machine, gift wrapping paper roll slitting rewinidng machine
