Continuous business form machinery

PPD Continuous computer form paper collator machine

Technical Data

Adopting Frequency stepless speed regulation, Servo paper-feeding system, PLC auto-control, photo-electric detection, auto-stop, manual control at the beginning of paper feeding and pinhole paper guiding ensure the precision of paper going. Folding, numbering, coding, collating are all in
1 to 7 layers could be assembled one-time.
The operator could set the number in any size on the touch screen, no need to change the gear wheel and code base.


Technical Specification

Max. paper width 450mm
collating layer 1-7 layers
Max. working speed 30-100m/min
Diameter of the hole 4± 0.1mm
Max. coding part 7pcs
Min. coding part 1pc
Motor power 0.75+0.4KW
Voltage 220V.50Hz or any
Weight 550kg

Remark: If we adopt Gear type paper-feeding system to replace the Servo paper-feeding system, it is another model PPD-450C-II Numbering Collator the speed of numbering on is higher, but need to change the gear wheel and code base for different sizes of number:

Technical Specification

Max. paper width 420mm
collating layer 1-7 layers
Max. working speed 0-150m/min
Diameter of the hole 4± 0.1mm
Max. coding part 7pcs
Min. coding part 1pc
Voltage 220V/50HZ or any
Power 1.5KW
Weight 650kg


Machine working as horizontal, we can make it to be vertical upon buyer request.

With any of inquirie,please free to contact us.
